How To: Display Real-Time CPU Usage In Total Launcher

Due to Android platform security and SELinux restrictions introduced in Android 8.0+ (Oreo), Total Launcher can no longer read system CPU metrics directly from /proc/stat. This guide details how to query system CPU usage via elevated ADB/Shizuku shell commands in Tasker and push that value into a Total Launcher Text Variable on the home screen.

Before setting up the background broadcast, create the graphic text element in Total Launcher that will listen for the value.

1. Enter Edit mode in Total Launcher (long-press empty space or tap the Launcher edit handle).
2. Tap Add (+) > Graphic > Default > Text.
3. Tap the newly placed text object to open its property dialog, then select the Edit (Gear/Pencil) icon.
4. In the text input field:
   1. * Delete the default text placeholder.
   2. Scroll through the dynamic insert options and choose Advanced: Variable (or format the variable tag manually).
   3. Set the variable placeholder to:

      • %cpu_val%

   4. (Note: Can add suffix text if desired, e.g., "CPU: %cpu_val%" to output CPU: 18%).
5. Adjust typography, font color, size, and alignment to suit the theme layout.
6. Tap the checkmark to confirm and exit Edit mode.

Now create the task that samples current CPU load and sends the broadcast intent to Total Launcher.

1. Create the Task
   1. Open Tasker and switch to the Tasks tab.
   2. Tap the + button at the bottom right to create a new task and name it:
      • Update TL CPU
2. Query CPU Utilization (Run Shell)
   1. Tap + to add an action.
   2. Select Code > Run Shell (or use Shizuku / Tasker ADB command).
   3. Enter the following command into the Command field:

      • top -b -n 1 | grep "User" | head -n 1

   4. Alternative lightweight one-liner for devices with `dumpsys` access:*

      • dumpsys cpuinfo | grep "TOTAL:" | awk '{print $1}'

   5. Under Store Output In, enter:

      • %cpu_raw

   6. Ensure Use Root or Use ADB WiFi / Shizuku is checked (unprivileged standard shell cannot read top system processes on modern Android versions).
3. Parse and Format the Percentage
   • Depending on the shell command output, extract the numeric value:
   1. Tap + > Variables > Variable Search Replace.
   2. Variable: %cpu_raw
   3. Search: [0-9]+(?=%) (or [0-9]+ to match the first integer).
   4. Check Store Matches In Array: %cpu_out.
   5. *(Optional)* If %cpu_out1 is empty, set a fallback: Variable > Variable Set > Name %cpu_val To %cpu_out1 (or To 0 if unset).
4. Broadcast the Variable to Total Launcher
   • Total Launcher supports direct integration via the plugin as well as standard broadcast intents.
   1. Option A (Using the Total Launcher Tasker Plugin):
      1. Tap + > Plugin > Total Launcher.
      2. Select Configuration / Edit.
      3. Choose Set Variable.
      4. Set Variable Name: cpu_val
      5. Set Value: %cpu_val
      6. Tap the checkmark to save the plugin action.
   2. Option B (Using Send Intent):
      1. Tap + > System > Send Intent.
      2. Action: com.ss.launcher.total.action.SET_VARIABLE
      3. Package: com.ss.launcher2
      4. Extra: var:cpu_val
      5. Extra: value:%cpu_val
      6. Target: Broadcast Receiver

• Because continuous 1-second sampling can consume battery, an interval of 5 to 15 seconds while the display is active is recommended.

1. In Tasker, navigate to the Profiles tab.
2. Tap + > State > Display > Display State > Set to On.
3. Link this profile to the task Update TL CPU.
4. Open the task and add a loop structure (or use a Time Context repeating every 2 minutes for ambient monitoring):
   1. Anchor: LoopStart
   2. Perform Action: (Execute shell & send variable steps)
   3. Task > Wait > Set to 5 Seconds (or 10 Seconds).
   4. Task > Goto > Type: Action Label > Label: LoopStart (Add condition: IF %SCREEN ~ on).

Following the SELinux restrictions implemented in modern Android versions, Total Launcher cannot query /proc/stat directly for system CPU data. This guide walks through configuring MacroDroid (via ADB Hack or Shizuku) to extract live CPU utilization and update a Total Launcher Text Variable on the home screen.

• First, set up the on-screen graphic text item that displays the received value.

1. Long-press an empty space or tap the Launcher edit handle to enter Edit mode.
2. Tap Add (+) > Graphic > Default > Text.
3. Tap the new text item to open its property dialog, then select the Edit (Gear/Pencil) icon.
4. In the text input field:
   1. Clear the default text.
   2. Insert the custom variable placeholder:

      • %cpu_val%

   • (Note: You can include custom labels or formatting, e.g., "CPU: %cpu_val%" to output CPU: 24%).
5. Adjust typography, size, color, and positioning as desired.
6. Tap the checkmark to save and exit Edit mode.

• Before building the macro, configure two local variables to store the raw output and the parsed numeric percentage.

1. Open MacroDroid and tap Variables (or expand the Variables drawer at the bottom of the Macro edit screen).
2. Tap + to add a new variable:
   1. Name: cpu_raw
   2. Type: String
3. Tap + to add a second variable:
   1. Name: cpu_val
   2. Type: String (or Integer)

1. Create the Macro and Define Triggers
   1. Open MacroDroid and tap Add Macro.
   2. Set the macro name at the top to:
      • Update TL CPU
   3. Under Triggers (red section), tap +:
   4. Screen & Speaker > Screen On/Off > Screen On.
2. *(Optional secondary trigger for ambient updates):*
   1. Tap + under Triggers > Date/Time > Regular Interval > Set to 10 seconds (or 30 seconds) > Under Constraints, add Screen On so it only fires while the display is awake.
3. Query System CPU Load
   1. Under Actions (blue section), tap +.
   2. Navigate to Applications > Shell Script.
   3. In the script editor:
      1. Select Shizuku or ADB Hack (do not use Non-rooted unless granted dump rights).
      2. Enter the following command into the script field:

         • dumpsys cpuinfo | grep "TOTAL:" | awk '{print $1}'

      3. Under Output to variable, select:

         • cpu_raw

   4. Tap OK to save the action.
4. Parse and Clean the Output
   • Strip extra formatting or percentage signs to isolate the pure numeric value:
   1. Tap + under Actions > Variables > Text Manipulation.
   2. Select Extract text (Regex).
      1. Source variable: cpu_raw
      2. Regular expression:

         • [0-9]+

      3. Destination variable: cpu_val
   3. Tap OK.
5. Broadcast the Variable to Total Launcher
   • Send the broadcast intent directly to Total Launcher's receiver:
   1. Tap + under Actions > Connectivity > Send Intent.
   2. Configure the intent parameters exactly as follows:
      1. Action: com.ss.launcher.total.action.SET_VARIABLE
      2. Package: com.ss.launcher2
      3. Target: Broadcast
      4. Extra 1 parameter: var
      5. Extra 1 value: cpu_val
      6. Extra 2 parameter: value
      7. Extra 2 value: [lv=cpu_val] *(Select via the triple-dot menu or type `[lv=cpu_val]` to pass the local variable)*
   3. Tap OK to save the action.
6. Save and Test
   1. Tap the back arrow or the checkmark icon in the bottom-right corner to save the macro.
   2. In the macro overview screen, tap the three dots in the upper-right corner and select Run Actions (or Test Macro) to test execution.
   3. Return to the home screen; the text object will reflect the current live CPU percentage.
